gear drive farmer use low consumption
Basic Info
Model No.: Golddafeng1304
Product Description
Chinese FOTON LOVOL TB404 130 Hp 4wd Farm Tractor with CE
TB Series Wheel tractor----from 120 to 150HP, Basic Specifciation as following
Quanchai/Xinchai Engine,8.3-20/12.4-28 tyre,12+12 shuttle shift,10" double action clutch,double speed PTO,4WD,Hydraulic drive,suspension group
TB Series Wheel tractor----from 70HP to 80HP, Basic Specifciation as following
Quanchai/Xinchai Engine,8.3-24/14.9-30 Tyre,12+12 Shuttle shift,11 " double action clutch,double speed PTO,4WD,Hydraulic Steering,forced lifting and dropping,suspension group
TD Series Wheel tractor-----from 90HP to 120HP, Basic Specifciation as following
YTO Engine,,12.4-24 front tyre,16.9-34 rear tyre,16+8 Shuttle shift(Creeping shift optional),4WD,12" double action clutch,Hydraulic Drive,Double Speed PTO,suspension group,forced lifting and dropping,multitandem Valve
TF Series Wheel Tractor -----From 130HP to 150HP, Basic Specifciation as following
TF Chassis,YTO Engine,14.9-26 front tyre,18.4-38 rear tyre,16+8Shuttle shift,4WD,13"double action clutch,Hydraulic Drive,reinforced front axle,Double Speed PTO,suspension group,forced lifting and dropping,multitandem valve
| SPECIFICATIONS FOR FOUR WHEELED DRIVE TRACTOR | |||
| Engine | Model | / | WP6G130E311 |
| Type | / | vertical, water-cooled, four-stroke, direct injection | |
| Rated Power | Kw | 95.6 | |
| The number of Cylinder | / | 6 | |
| Main performance parameters | Steering Type | / | hydraulic steering |
| Clutch | / | dry,single disc, independent dual-stage | |
| Walk System(Front Tire/Rear Tire) | / | 13.6-24/16.9-34 | |
| Drive | Drive type | / | 4×4 |
| Wheeltrack | mm | 2604 | |
| Wheel Track(Front/Rear) | mm | 1554.1654.1682.1740.1782.1840.1868.1968/1610~2210 | |
| Min. Operation Weight | Kg | 4580 | |
| Gears | / | 16F+8R | |
| PTO Axle Power | Kw | 82 | |
| Max. Tractive Effort | Kn | 28 | |
| | L | mm | 5060 |
| W | mm | 2330 | |
| H | mm | 2983 | |
| Working equipment | Three-Point Suspension | / | Category Ⅱ |
| Hydraulic pumb type | / | gear pumb | |
| hydraulic output valva | / | 2 ways | |
| Others | PTO axle splines number | / | 8 |
| PTO Speed | R/Min | 760/850(540/1000.540/760.760/1000 is optional) | |
| Max. Lifting Capacity | Kn | 23.4 | |
